Configuration Guide 146
Configuring 802.1Q VLAN 802.1Q VLAN Configuration
VLAN Name Status Ports
------- -------- --------- ---------
2 RD active
Switch(config-vlan)#end
Switch#copy running-config startup-config
2.2.2 Configuring the Port
Follow these steps to configure the port:
Step 1 configure
Enter global configuration mode.
Step 2 interface {fastEthernet
port
| range fastEthernet
port-list
| gigabitEthernet
port
| range
gigabitEthernet
port-list
| ten-gigabitEthernet
port
| range ten-gigabitEthernet
port-list
|
port-channel
port-channel-id
| range port-channel
port-channel-list
}
Enter interface configuration mode.
Step 3 switchport pvid
vlan-id
Configure the PVID of the port(s). By default, it is 1.
vlan-id
: The default VLAN ID of the port with the values between 1 and 4094.
Step 4 switchport check ingress
Enable or disable Ingress Checking. With this function enabled, the port will accept the
packet of which the VLAN ID is in the port’s VLAN list and discard others. With this function
disabled, the port will forward the packet directly.
Step 5 switchport acceptable frame {all | tagged}
Select the acceptable frame type for the port and the port will perform this operation before
Ingress Checking.
all: The port will accept both the tagged packets and the untagged packets.
tagged: The port will accept the tagged packets only.
Step 6 end
Return to privileged EXEC mode.
Step 7 copy running-config startup-config
Save the settings in the configuration file.
The following example shows how to configure the PVID of port 1/0/5 as 2, enable the
ingress checking and set the acceptable frame type as all:
Switch#configure
Switch(config)#interface gigabitEthernet 1/0/5
Switch(config-if)#switchport pvid 2
