Configuration Guide 758
Configuring SNMP & RMON Notification Configurations
3
Notification Configurations
With Notification enabled, the switch can send notifications to the NMS about important
events relating to the device’s operation. This facilitates the monitoring and management
of the NMS.
To configure SNMP notification, follow these steps:
1) Configure the information of NMS hosts.
2) Enable SNMP traps.
Configuration Guidelines
To guarantee the communication between the switch and the NMS, ensure the switch and
the NMS are able to reach one another.
3.1 Using the GUI
3.1.1 Configuring the Information of NMS Hosts
Choose the menu MAINTENANCE > SNMP > Notification > Notification Config and click
to load the following page.
Figure 3-1 Adding an NMS Host
Follow these steps to add an NMS host:
1) Choose the IP mode according to the network environment, and specify the IP address
of the NMS host and the UDP port that receives notifications.
