TP-Link T1500 Series - Page 287

Configuring Layer 2 Multicast Multicast Filtering Configuration
Configuration Guide
265
Step 4 ipv6 mld snooping max-groups
maxgroup
Configure the maximum number of multicast groups the port can join.
maxgroup
: Specify the maximum number of multicast groups the port can join. Valid values
range from 1 to 511.
Step 5 ipv6 mld snooping max-groups action {drop | replace}
Specify the action towards the new multicast group when the number of multicast groups the
port joined exceeds max group.
drop: Drop all subsequent membership report messages, and the port join no more new
multicast groups.
replace: Replace the existing multicast group owning the lowest multicast MAC address with
the new multicast group.
Step 6 show ipv6 mld profile [
id
]
Show the detailed MLD profile configuration.
show ipv6 mld snooping interface [fastEthernet [
port-list
] | gigabitEthernet [
port-list
] | ten-
gigabitEthernet [
port-list
] | port-channel [
port-channel-list
] ] max-groups
Show the multicast group limitation on the specified port(s) or of all the ports.
Step 7 end
Return to privileged EXEC mode.
Step 8 copy running-config startup-config
Save the settings in the configuration file.
The following example shows how to bind the existing Profile 1 to port 1/0/2, and specify
the maximum number of multicast groups that port 1/0/2 can join as 50 and the Overflow
Action as Drop:
Switch#configure
Switch(config)#interface gigabitEthernet 1/0/2
Switch(config-if)#ipv6 mld snooping
Switch(config-if)#ipv6 mld filter 1
Switch(config-if)#ipv6 mld snooping max-groups 50
Switch(config-if)#ipv6 mld snooping max-groups action drop
Switch(config-if)#show ipv6 mld profile
MLD Profile 1
...
Binding Port(s)
