Configuration Guide 486
Configuring QoS Appendix: Default Parameters
DSCP 802.1p Priority
16 to 23 2
24 to 31 3
32 to 39 4
40 to 47 5
48 to 55 6
56 to 63 7
Table 7-5 Default Settings of DSCP Remap Configuration
Original
DSCP
New DSCP Original
DSCP
New DSCP Original
DSCP
New DSCP
0 0 be (000000) 22 22 af23 (010110) 44 44
1 1 23 23 45 45
2 2 24 24 cs3 (011000) 46 46 ef (101110)
3 3 25 25 47 47
4 4 26 26 af31 (011010) 48 48 cs6 (110000)
5 5 27 27 49 49
6 6 28 28 af32 (011100) 50 50
7 7 29 29 51 51
8 8 cs1 (001000) 30 30 af33 (011110) 52 52
9 9 31 31 53 53
10 10 af11 (001010) 32 32 cs4 (100000) 54 54
11 11 33 33 55 55
12 12 af12 (001100) 34 34 af41 (100010) 56 56 cs7 (111000)
13 13 35 35 57 57
14 14 af13 (001110) 36 36 af42 (100100) 58 58
15 15 37 37 59 59
16 16 cs2 (010000) 38 38 af43 (100110) 60 60
17 17 39 39 61 61
18 18 af21 (010010) 40 40 cs5 (101000) 62 62
19 19 41 41 63 63
20 20 af22 (010100) 42 42
21 21 43 43
