Configuring ACL ACL Configuration
Configuration Guide
577
4) In the Policy section, enable or disable the Rate Limit feature for the matched packets.
With this option enabled, configure the related parameters.
Figure 2-7 Configuring Rate Limit
Rate Specify the transmission rate for the matched packets.
Burst Size Specify the maximum number of bytes allowed in one second.
Out of Band Select the action for the packets whose rate is beyond the specified rate.
None: The packets will be forwarded normally.
Drop: The packets will be discarded.
5) In the Policy section, enable or disable the QoS Remark feature for the matched
packets. With this option enabled, configure the related parameters, and the remarked
values will take effect in the QoS processing on the switch.
Figure 2-8 Configuring QoS Remark
DSCP Specify the DSCP field for the matched packets. The DSCP field of the
packets will be changed to the specified one.
Local Priority Specify the local priority for the matched packets. The local priority of the
packets will be changed to the specified one.
802.1p Priority Specify the 802.1p priority for the matched packets. The 802.1p priority of
the packets will be changed to the specified one.
6) Click Apply.
