Technical data
 TR-Electronic GmbH 2016, All Rights Reserved Printed in the Federal Republic of Germany
Page 16 of 153 TR-EMO-BA-GB-0022 v03 09/29/2020
3 Technical data
3.1 Current firmware versions
MP-060-ETC
Device name .......................................................
MP-060-ETC
Firmware file name ............................................
M01907000
Motor type ..........................................................
"Dunker BG65x25", 60W, 24V
CoE Manufacturer code ....................................
1289 = "TR Electronic GmbH"
CoE Device name ..............................................
"EncoTRive RELC"
CoE Product code .............................................
736055
CoE Revision number .......................................
0x10001000 = "V1.1"
CoE Hardware version ......................................
"736055a"
CoE Software version .......................................
"V1.1 7-May-2019"
MP-200-ETC
Device name .......................................................
MP-200-ETC
Firmware file name ............................................
M01707000
Motor type ..........................................................
"Schneider Electric BDM 754", 300W, 48V
CoE Manufacturer code ....................................
1289 = "TR Electronic GmbH"
CoE Device name ..............................................
EncoTRive RELC
CoE Product code .............................................
736055
CoE Revision number .......................................
0x10001000 = "V1.1"
CoE Hardware version ......................................
736055a
CoE Software version .......................................
V1.1 7-May-2019
3.2 Electrical characteristics
Logic supply
24 V version ................................................
+10...+36 VDC
60 V version ................................................
+10...+60 VDC
Polarity protection .......................................
yes
Current consumption, logic..............................
300 mA, 3 W
Power supply .....................................................
0...+54 VDC
Polarity protection .......................................
yes
Current consumption ........................................
4...20 A, 50...300 W; depending of the motor
Drive ....................................................................
3 phase field oriented control for brushless DC motors
PWM and regulator cycle ..................................
100 µs
