TR-Electronic MP-200 - Manufacturer-Specific Objects; Object 0 X2 Ef3: Trabedata.mvi16

Printed in the Federal Republic of Germany  TR-Electronic GmbH 2016, All Rights Reserved
09/29/2020 TR-EMO-BA-GB-0022 v03 Page 83 of 153
9.3 Manufacturer-specific objects
Index (h)
Object
Name
Data length
Attr.
Page
Parameter
2EF3
RECORD
TrAbeData.MVI16
Integer16
ro
83
2F04
RECORD
DS402M.MPU32
Unsigned32
rw
85
2F0E
RECORD
DS402M.MPX
-
rw
89
9.3.1 Object 0x2EF3: TrAbeData.MVI16
Object code
ARRAY
Description
For service purposes only
Subindex 0: Number of entries
Data type
UNSIGNED8
Attribute
ro
Default
8
Min
-
Max
-
PDO mapping
-
Description
Number of following entries
Subindex 1: Current temperature 1/°C
Data type
INTEGER16
Attribute
ro
Default
-
Min
-2
15
Max
+2
15
-1
PDO mapping
yes
Description
-
Subindex 2: Current temperature 2/°C
Data type
INTEGER16
Attribute
ro
Default
-
Min
-2
15
Max
+2
15
-1
PDO mapping
yes
Description
-
Subindex 3: Current temperature 3/°C
Data type
INTEGER16
Attribute
ro
Default
-
Min
-2
15
Max
+2
15
-1
PDO mapping
yes
Description
-
