9.2.7 Object 0x1010: Save Backup Parameters
Object name
Save Backup Parameters
Object code
ARRAY
Description
This object supports the saving of parameters in non-volatile memory
(EEPROM).
Changed parameters are accepted only if the storage command is executed! The
storage command is performed if the signature “save” is written to subindex 1.
Subindex 0: Number of entries
Data type
UNSIGNED8
Attribute
ro
Default
4
Min
-
Max
-
PDO mapping
-
Description
Contains the largest array subindex
Subindex 1: Store all parameters
Data type
UNSIGNED32
Attribute
rw
Default
0
Min
-
Max
-
PDO mapping
-
Description
Stores all storable parameters. The parameters are only
stored if the value
0x65766173
is written. This is the numeric value resulting from the
"save"
character string ('s' : 0x73, 'a': 0x61, 'v' : 0x76, 'e': 0x65).
Subindex 3: Store application parameters (0x6xxx-objects)
Data type
UNSIGNED32
Attribute
rw
Default
0
Min
-
Max
-
PDO mapping
-
Description
see subindex 1
Subindex 4: Store manufacturer-specific parameters (0x2xxx-objects)
Data type
UNSIGNED32
Attribute
rw
Default
0
Min
-
Max
-
PDO mapping
-
Description
see subindex 1
