9.3.2 Object 0x2F04: DS402M.MPU32
Object code
ARRAY
Description
Masking of the digital inputs/outputs, ballast circuit
Subindex 0: Number of entries
Data type
UNSIGNED8
Attribute
ro
Default
0
Min
0
Max
14
PDO mapping
-
Description
Number of following entries
Subindex 1: Digital lnput And Mask
Data type
UNSIGNED32
Attribute
rw
Default
-
Min
-2
31
Max
+2
31
-1
PDO mapping
yes
Description
disables individual bits of the input signal (0x60FD)
Subindex 2: Digital lnput Negation Mask
Data type
UNSIGNED32
Attribute
rw
Default
-
Min
-2
31
Max
+2
31
-1
PDO mapping
yes
Description
negates individual bits of the input signal (0x60FD)
Subindex 3: Output And Mask
Data type
UNSIGNED32
Attribute
rw
Default
-
Min
-2
31
Max
+2
31
-1
PDO mapping
yes
Description
disables individual bits of the output signal (0x60FE)
Subindex 4: Digital Output Negation Mask
Data type
UNSIGNED32
Attribute
rw
Default
-
Min
-2
31
Max
+2
31
-1
PDO mapping
yes
Description
negates individual bits of the output signal (0x60FE)
