TR-Electronic MP-200 - Status Word; Table 22: Status Word (Object 0 X6041), Cyclic Synchronous Torque (CST) Operating Mode

DSP 402 drive profile
 TR-Electronic GmbH 2016, All Rights Reserved Printed in the Federal Republic of Germany
Page 54 of 153 TR-EMO-BA-GB-0022 v03 09/29/2020
5.7.2 Status word
Bit
STATUS WORD
0
Value 1: Ready to switch on
1
Value 1: Ready for operation
2
Value 1: Operating mode activated
3
Value 1: Error present
4
Value 1: Voltage switched on
5
Value 0: Quick stop active
6
Value 1: Not ready for operation
7
Value 1: Warning present
8
not used
9
Manual operation
0
No parameter access
via CAN bus
1
Parameter access
via CAN bus
10
not used
11
Value 1: Exit working range
Position value outside the preset range.
Definition via object 0x607D.
12
Drive follows the
command value
0
Target torque of object
0x6071 ignored
1
Target torque of object 0x6071 used as
input to torque control loop
13-15
not used
Table 22: Status word (object 0x6041), “Cyclic synchronous torque (CST)” operating mode
