Subindex 9: Ls/µH (Stator inductivity)
Data type
UNSIGNED32
Attribute
rw
Default
-
Min
-2
31
Max
+2
31
-1
PDO mapping
no
Description
The proportional gains of the PI current controller are set by
the DC voltage, divided according to stator inductivity, in
order to maintain the necessary switch-off frequency of the
closed control loop.
Depending on the motor type, this inductivity can fall to 1/3 if
the stator current is increased from 0 to the nominal value. In
order to prevent gains that are too high and cause vibrations,
the stator inductivity should be measured at maximum
current.
Subindex 10: RegPosrKS
Data type
UNSIGNED32
Attribute
rw
Default
-
Min
-2
31
Max
+2
31
-1
PDO mapping
no
Description
for internal purposes only
Subindex 11: Max. duration of pos. ramp/Tc
Data type
UNSIGNED32
Attribute
rw
Default
-
Min
-2
31
Max
+2
31
-1
PDO mapping
no
Description
for internal purposes only
Subindex 12: LsiscC30
Data type
UNSIGNED32
Attribute
rw
Default
-
Min
-2
31
Max
+2
31
-1
PDO mapping
no
Description
for internal purposes only
