5-27 Expansion Modules
FO-VFKB Fibre Optic Keypad/Display Interface
Trio Motion Technology
gram to accept run-time data from an operator or scroll through a menu for
example. Connection to the keypad is made via a short ribbon cable between
the 16 way IDC plug on the back of the FO-VFKB module and the similar con-
nector on the back of the keypad.
Power Requirements
A 24V DC power supply is required to drive the FO-VFKB. This is also the supply
for the display so must be capable of delivering at least 750mA. Power is
applied on the two way disconnect terminal. The board is diode protected
against reverse voltages being applied to the power connector. With power
applied to the board the green LED on the top of the board should be lit.
Data Connection
The data connection is identical to that of a membrane keypad.
Function IDC plug pin no. Function
Row 4
12Column 0
Row 1
34 Column 7
Column 4
56Row 2
Column 1
78Column 8
Column 5
910Row 3
Column 2
11 12 Column 9
Column 6
13 14 Column 3
Row 0
15 16 Column 10
Summary of Features P504 FO-VFKB
Size
150mm x 64mm
Weight
0.065 Kg
Operating Temperature
0-45 degrees C
Keypad
5x11 debounced keypad decoder
with key on/key off option
V/F Display
Direct connection on DIL header
Data Connection
Fibre optic data link
Power supply
24V DC external power supply
required
