TRUE SOLTEC CFM-BL10Pro - Sensor

CFM-BL10Pro General instruction manual
12 / 87
15
STOP NC
Blue
Green/Black dot 2
Relay will be inverted when any
errors happen, or CFM is in
Parameter mode. Relay will be
connected when CFM turns to OPE
or Teach mode and recovers from
Error mode.
16
COM
Blue / White
Green/Red dot 2
STOP relay common
17
CH1 EJECT
Gray
Gray/Black dot 2
CH1judgement signal. This signal
can be used for either OK or Not
OK.
18
Extra Input
Gray / White
Gray/Red dot 2
19
TEACH mode
Brilliant Green
White/Black dot 1
This signal will be high once CFM is
in Teach mode.
20
Extra Input
Brilliant Green / White
White/Red dot 2
21
Extra Input
Pink
Orange/Black dot 3
22
ACK
Pink / White
Orange /Red dot 3
Response signal which is output
when Program number is correctly
changed.
23
Extra Input
Brilliant Blue
Yellow/Black dot 3
24
GND
Brilliant Blue / White
Yellow/Red dot 3
Common for Input/Output signals
except for Pin No. 14 to 16.
Connect GND of a press machine.
25
Black
Green/Black dot 3
1.5. Sensor
Piezoelectric strain sensor PSS series and Piezoelectric force sensor FTW series
can be used for CFM-BL10Pro. These sensors have characteristics below.
Piezoelectric strain sensor PSS
PSS sensor detects strain generated in crimping machine’s body in proportion to
force applied to machine during crimping. This strain is just a little, but PSS sensor
can tell the difference between good and bad samples because its sensitivity is very
high.
Its installation is very easy, and the sensor can be installed the almost all manual
crimping machines. Depending on the rigidity of crimping machine body, the
sensitivity can be selected among PSS20: Low, PSS50: Middle and PSS100: High.
