Description
Language
Choose a language from Japanese or English.
Help
Display Headroom software version.
Back
Close Headroom software.
Clear
Clear all data on the screen.
Report
Print data on the screen.
Other Settings
Inspection Target of
defects
Choose 1 if you would like to detect 1/7 strands out/ break
However, the “Supervisable” area becomes narrower.
Increase the figure of wires (e.g. 2/7, 3/7) will expand the
“Supervisable” area.
Total Strands count
Select 7 if you prefer to detect 1/7 strands out/ break.
Select 19 if you would like to detect 1/19 strands out.
In case of 19, the “Superviable” area is smaller than 7.
Normal crimping /
Terminal only
crimping Threshold
(*)
This figure represents the position of the red horizontal
line in the bar graph (mV).
Either entering a new number or directly dragging the line
will change this threshold.
Normal crimping
count (*)
Count the number of good crimps, which have the peak
force higher than “Normal crimping/ Terminal only crimping
threshold”
Terminal only
crimping count (*)
Count the number of bad crimps, which have the peak
force lower than “Normal crimping/ Terminal only crimping
threshold”
Normal crimping
(peak value) (*)
Show average peak force of all good crimps
Terminal only
crimping (peak
value) (*)
Show average peak force of all crimps without wire
Head Room (*)
Calculate data of all crimps and display Head room rate
(%)
Normal dispersion
(*)
Calculate data of all good crimps and show Normal
dispersion rate (%)
Note
Enter note that you want to keep on the report when
printing it.
*The result will be changed depending on the setting selection.
