HP10E / HP12E / HP15E / HP20E - Dairy design6. Graphical control
6-72 © VEMAG 2013
Number Message Cause Remedy
920 Twist drive application Fault in the application module.
This fault occurs in combination
with other fault numbers.
Note the numbers of all current
faults and contact VEMAG Service.
922 Main drive manual Main drive operated manually. Release manual drive button S10.
923 Twist drive manual Twist drive operated manually. Release manual drive button S9.
924 Infeed drive manual Feed unit drive operated manually. Release manual drive button S10.
925 Blade drive timeout The reference movement of the
machine‘s internal blade drive took
too long.
Check the reference sensor and
the blade drive‘s application
module. Make a note of the error
number and inform the VEMAG
Customer Service team.
929 Belt drive not found Belt drive not found on CAN bus. Check power supply at drive con-
troller FU4 and that the CAN bus
lines are correctly wired.
931 Communication belt drive CAN bus communication with belt
drive interrupted.
Check that CAN bus line is wired
correctly.
932 Unexpected belt drive Uncongured belt drive found on
CAN bus.
Activate the belt drive in the PC
if necessary.
933 Belt drive inhibit Controller for belt drive not
released.
Check controller release at FU4,
terminal 31.
935 Belt drive manual Belt drive operated manually. Release manual drive button.
937 Blade drive timeout The machine‘s internal blade drive
took too long to reach its starting
position.
Check the reference sensor and
the blade drive‘s application
module. Make a note of the error
number and inform the VEMAG
Customer Service team.
940 Attachment 2 ready Attachment 2 is ready (e.g. han-
ging machine).
-
942 External drive 1 not found The PC could not nd the rst
drive controller from attachment 2
on the CAN bus.
Check the power supply of the
rst drive controller and that the
external CAN bus has been wired
correctly (connector + socket).
943 External drive 1 commu-
nication
CAN bus communication to the
rst drive controller of attachment
2 was interrupted.
Check that the CAN bus has been
wired correctly.
944 No release for external
drive 1
The rst drive of attachment 2 is
not released.
Check the voltage on terminal 31.
945 External drive 1 applica-
tion error
There is a communication error
between the application module
of attachment 2 and A1 (PC). This
error occurs in combination with
other error numbers.
Make a note of the numbers of all
errors displayed before this error
and contact VEMAG Customer
Service.
946 External drive 1 manual The rst drive of attachment 2 is
operated manually.
Release manual drive button.
