HP10E / HP12E / HP15E / HP20E - Dairy design 6. Graphical control
6-73© VEMAG 2013
Number Message Cause Remedy
947 External drive 1 timeout The reference movement of the
rst drive of attachment 2 took too
long.
Check the reference sensor and
the application module. If there is
no error, contact VEMAG Custo-
mer Service.
950 External drives ready The external drive(s) are ready. --
952 External drive 1 not found External drive 1 could not be found
on the CAN bus.
Check power supply at drive con-
troller FU1 and that the CAN bus
lines are correctly wired.
953 External drive 1 commu-
nication
CAN bus communication to exter-
nal drive 1 was interrupted.
Check that CAN bus line is wired
correctly.
954 No release for external
drive 1
There is no controller release for
external drive 1.
Check controller release to FU1,
terminal 31.
955 External drive 1 applica-
tion error
Fault in the application module.
This fault occurs in combination
with other fault numbers.
Make a note of the numbers of all
errors displayed before this error
and inform the VEMAG Customer
Service team.
956 External drive 1 manual External drive 1 is operated by
hand.
Release manual drive button S10.
957 External drive 1 timeout The reference movement of the
machine‘s external drive 1 took too
long.
Check the reference sensor and
the blade drive‘s application
module. Make a note of the error
number and inform the VEMAG
Customer Service team.
1000 - 2999 Main drive The main drive controller is report-
ing a fault.
Note the fault number and contact
VEMAG Customer Service.
3000 - 4999 Twist drive The linking drive controller is
reporting a fault.
Note the fault number and contact
VEMAG Customer Service.
5000 - 6999 Infeed drive The feed unit drive controller is
reporting a fault.
Note the fault number and contact
VEMAG Customer Service.
7000 - 8999 Belt drive The belt drive controller is report-
ing a fault.
Note the fault number and contact
VEMAG Service.
21000 -
49999
External drive of attach-
ment 1
There is an error in the external
drive controller.
Note the fault number and contact
VEMAG Customer Service.
20000 Attachment 1 ready Attachment 2 is ready (e.g. LPG,
FSL).
-
20001 Safety chain open - -
20002 No external release signal External release signal not present -
20003 Voltage F+24 V fuse F4 Fuse F4 is defective -
20004 Unexpected linking head
movement
Spindle drive moves the linking
head in the casing brake even
though two-handed operation has
not been activated
-
20005 Linking head return si-
gnals faulty
Spindle drive encoder return not
working
-
