Maintenance
5562−1/A1
Winterthur Gas & Diesel Ltd.
3/ 3
4. Cleaning the filter
1) Remove the oil inlet pipe ’OE’ and the union (1, Fig. 3).
2) Loosen the filter (3) and clean it. If necessary replace it.
3) Oil the filter (3), screw it into the cover (2) and apply a torque of 10 Nm.
BA
OE
OIL
WCH00763
BE
123
FUEL OIL
Fig. 3
5. Storage on board
The spare parts must be carefully protected against corrosion.
D The PCV has to be free from any dirt, oil and grease.
D Apply coating liquids (e.g. Tectil 506, ISOTEC 337 or similar) on the surfaces to
be preserved.
D All blind holes and tapped holes must be plugged.
Especially consignments transported overseas must be well protected against
adverse climatic conditions (intense cold, rain, high humidity, etc.) and kept in a
closed box.
2015
Fuel Pressure Control Valve: Removal and Installation
