WinGD X92 - Page 522

Maintenance9403−3/A1
Winterthur Gas & Diesel Ltd.
6/ 11
Tool 94215A Pre-tensioning jack for elastic bolts to cylinder cover
1 Piston 7 Vent screw
2 Back-up ring
O-ring
Sealing ring
8 Adapter piece
3 9 Closing valve
4 Cylinder
5 Back-up ring
O-ring
Sealing ring
6
94215A−KJ K
it with back-up and O-rings
for pre-tensioning J
ack
7
MAX. STROKE 25 MM
2
3
5
6
94215A−KJ
WCH0202933
Fig. 10
Fig. 11
1
4
8
9
2015
Hydraulic Pre-tensioning Jacks: Storing, Servicing and Maintenance
