Maintenance9403−3/A1
Winterthur Gas & Diesel Ltd.
8/ 11
Tool 94315 Pre-tensioning jacks for elastic bolts to upper connecting rod
bearing
1 Piston 7 Vent screw
2 Back-up ring
O-ring
Sealing ring
8 Adapter piece
3 9 Closing valve
4 Cylinder
5 Back-up ring
O-ring
Sealing ring
6
94315−KJ K
it with back-up and O-rings
for pre-tensioning J
ack
1
4
7
8
9
MAX. STROKE 6 MM
2
3
5
6
94315−KJ
WCH02937
Fig. 14 Fig. 15
2015
Hydraulic Pre-tensioning Jacks: Storing, Servicing and Maintenance
