Maintenance0360−1/A1
Winterthur Gas & Diesel Ltd.
2/ 3
Group Component Execution kg
3306 Connecting rod
With elastic stud and nut for bottom end
bearing
complete 6900
3306 Bearing cover for bottom end
bearing with elastic studs
complete 975
3310 Bearing shell for bottom end bearing Lower
upper
85
112
3312 Bearing cover for top end bearing 977
3315 Bearing shell for top end bearing 185
3326 Crosshead pin
Crosshead with guide shoes
Guide shoe
complete
complete
4824
7592
1300
3403 Piston with piston rod
Piston head
Piston skirt
Piston rod
Spraying plate with oil pipe
Piston rings
complete 5100
1400
231
3170
218
10−16
3603 Toggle lever to piston cooling and
crosshead lubrication
complete 240
4
4106 Gear wheel on crankshaft 2-part, complete 5062
4325 Shut-off for starting air 501
5
5551 Servo oil pump 230
5552 Supply unit with 6 fuel pumps and 3 oil
pumps
10100
5552 Camshaft with gear wheels compl.for 6 fuel
pumps
1050
5556 Fuel pump complete 407
5612 Exhaust valve control unit complete 59.1
2015
Individual Components per Piece in kg
