Xerox C315 User Manual

CCAAUUTTIIOONN——SSHHOOCCKK HHAAZZAARRDD:: To avoid the risk of electrical shock, do not use the fax feature during a
lightning storm.
CCAAUUTTIIOONN——SSHHOOCCKK HHAAZZAARRDD:: To avoid the risk of electrical shock when cleaning the exterior of the
printer, unplug the power cord from the electrical outlet and disconnect all cables from the printer before
proceeding.
CCAAUUTTIIOONN——PPOOTTEENNTTIIAALL IINNJJUURRYY:: If the printer weight is greater than 18kg (40lb), then it may
require two or more people to lift it safely.
CCAAUUTTIIOONN——PPOOTTEENNTTIIAALL IINNJJUURRYY:: When moving the printer, follow these guidelines to avoid personal
injury or printer damage:
• Make sure that all doors and trays are closed.
• Turn off the printer, and then unplug the power cord from the electrical outlet.
• Disconnect all cords and cables from the printer.
• If the printer has separate floor-standing optional trays or output options attached to it, then
disconnect them before moving the printer.
• If the printer has a caster base, then carefully roll it to the new location. Use caution when passing
over thresholds and breaks in flooring.
• If the printer does not have a caster base but is configured with optional trays or output options, then
remove the output options and lift the printer off the trays. Do not try to lift the printer and any
options at the same time.
• Always use the handholds on the printer to lift it.
• Any cart used to move the printer must have a surface able to support the full footprint of the printer.
• Any cart used to move the hardware options must have a surface able to support the dimensions of
the options.
• Keep the printer in an upright position.
• Avoid severe jarring movements.
• Make sure that your fingers are not under the printer when you set it down.
• Make sure that there is adequate clearance around the printer.
CCAAUUTTIIOONN——TTIIPPPPIINNGG HHAAZZAARRDD:: Installing one or more options on your printer or MFP may require a
caster base, furniture, or other feature to prevent instability causing possible injury. For more information
on supported configurations, contact the place where you purchased the printer.
CCAAUUTTIIOONN——TTIIPPPPIINNGG HHAAZZAARRDD:: To reduce the risk of equipment instability, load each tray separately.
Keep all other trays closed until needed.
CCAAUUTTIIOONN——HHOOTT SSUURRFFAACCEE:: The inside of the printer might be hot. To reduce the risk of injury from a
hot component, allow the surface to cool before touching it.
14
Xerox
®
C315 Color Multifunction Printer User Guide
Safety

Xerox C315 Specifications

General

Duplex printing	Yes
Print technology	Laser
Maximum resolution	4800 x 4800 DPI
Duplex printing mode	Auto
Print resolution black	1200 x 1200 DPI
Warm-up time (from sleep mode)	16 s
Time to first page (black, normal)	7.9 s
Time to first page (color, normal)	8 s
Print speed (black, normal quality, A4/US Letter)	33 ppm
Duplex print speed (black, normal quality, A4/US Letter)	16 ppm
Custom media width	98 - 216 mm
Maximum print size	216 x 356 mm
Custom media length	148 - 356 mm
Paper tray media types	Bond paper, Card stock, Envelopes, Glossy paper, Heavy paper, Labels, Letterhead, Lightweight paper, Plain paper, Pre-Printed, Recycled paper, Rough paper
Paper tray media weight	60 - 200 g/m²
Non-ISO print media sizes	Legal (media size), Letter (media size)
ISO A-series sizes (A0...A9)	A4, A5, A6
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 163 g/m²
Auto Document Feeder (ADF) media weight	52 - 120 g/m²
Auto Document Feeder (ADF) media weight (imperial)	14 - 32 lbs
USB connector	USB Type-A / USB Type-B
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Cabling technology	10/100/1000Base-T(X)
Ethernet LAN data rates	1000 Mbit/s
Mobile printing technologies	Apple AirPrint, Mopria Print Service
Internal memory	2048 MB
Processor cores	4
Processor frequency	1200 MHz
Card reader integrated	No
Sound pressure level (printing)	52 dB
Sound pressure level (duplex printing)	53 dB
Copier resize	25 - 400 %
Maximum copy resolution	600 x 600 DPI
Maximum number of copies	9999 copies
N-in-1 copy function (N=)	2, 4
Time to first copy (black, normal)	8.2 s
Time to first copy (color, normal)	9.1 s
Copy speed (color, normal quality, A4)	33 cpm
Display	LCD
Control type	Buttons, Touch
Product color	Blue, White
Display diagonal	4.3 \
Market positioning	Home & office
Scan to	File, Network folder, E-mail, USB, FTP
Scan drivers	ICA, TWAIN, WIA
Scanner type	Flatbed & ADF scanner
Maximum scan area	216 x 355 mm
Image formats supported	JPEG, JPG, TIFF
Document formats supported	PDF, XPS
Optical scanning resolution (black)	600 x 600 ppi
Mac operating systems supported	Mac OS X 10.14 Mojave, Mac OS X 10.15 Catalina, Mac OS X 10.15.3 Catalina, Mac OS X 11.0 Big Sur, Mac OS X 12.0 Monterey
Server operating systems supported	Windows Server 2008, Windows Server 2008 R2, Windows Server 2012, Windows Server 2012 R2, Windows Server 2019
Windows operating systems supported	Windows 10, Windows 11, Windows 8, Windows 8.1
Faxing	Color faxing
Fax memory	18 MB
Modem speed	33.6 Kbit/s
Fax forwarding to	E-mail, FTP, Folder
Fax coding methods	JBIG, JPEG, MH, MMR (Fax coding method), MR
Fax resolution (color)	300 x 300 DPI
PCL fonts	6
Printer fonts	PCL, PostScript
Printing colors	Black, Cyan, Magenta, Yellow
Duplex functions	Copy, Fax, Print, Scan
Maximum duty cycle	80000 pages per month
Recommended duty cycle	0 - 6000 pages per month
Number of PostScript fonts	158
Page description languages	PCL 5, PCL 6, PDF 1.7, PostScript 3, XPS
Cables included	AC
Included cartridge capacity (CMY)	1500 pages
Included cartridge capacity (black)	1000 pages
Total input capacity	251 sheets
Total output capacity	150 sheets
Maximum input capacity	901 sheets
Paper tray 1 input capacity	250 sheets
Total number of input trays	1
Maximum number of input trays	3
Multi-Purpose tray input capacity	1 sheets
AC input voltage	220 - 240 V
AC input frequency	47-63 Hz
Power consumption (max)	530 W
Power consumption (sleep)	1.44 W
Power consumption (standby)	26.2 W
Power consumption (printing)	360 W
Storage temperature (T-T)	10 - 32.2 °C
Operating relative humidity (H-H)	15 - 80 %
Harmonized System (HS) code	84433100
Package depth	600 mm
Package width	560 mm
Package height	570 mm
Package weight	30800 g

Weight and Dimensions

Depth	588 mm
Width	442 mm
Height	462 mm
Weight	27100 g
