February 2013
5-62
ColorQube® 9303 Family
PL 26.10
Parts Lists
PL 26.10 Consumables and Tools (1
of 2)
Item Part Description
1 008R90176 Cleaning fluid (IPA &
water)(WARNING)
2 – Ethernet crossover cable (PWS to
SBC PWB) (Not spared)
3 – Finisher bypass connector (Not
spared)
4 – Plastislip grease (Not spared)
5 – Disposable gloves (general
protection- see below for varaints)
(Qty. 100) (WARNING)
– 099P03227 Small
– 099P03228 Medium
– 099P03229 Large
– 099P03230 Extra large
6 019P03025 Microfibre cleaning cloth
7 108R00834 Magenta solid ink stick (Metered)
– 108R00830 Magenta solid ink stick (Sold)
– 108R00838 Magenta solid ink stick (Sold DMO)
8 108R00833 Cyan solid ink stick (Metered)
– 108R00829 Cyan solid ink stick (Sold USSG/
XCL/XE)
– 108R00837 Cyan solid ink stick (Sold DMO)
9 108R00835 Yellow solid ink stick (Metered)
– 108R00831 Yellow solid ink stick (Sold)
– 108R00839 Yellow solid ink stick (Sold DMO)
10 108R00836 Black solid ink stick (Metered)
– 108R00832 Black solid ink stick (Sold)
– 108R00840 Black solid ink stick (Sold DMO)
11 – Antistatic fluid (Not spared)
12 – Molub grease 777 (Not spared)
13 – Cable tie (P/O PL 31.10 Item 12)
14 – Foreign interface test tool (USSG/
XC)
15 008R12912 Staple cartridge (HVF - 100 sheet)
(1 x 5000)
– 008R12898 Staple cartridge (HVF- 100 sheet)
(3 x 5000)
– 008R12919 Staple cartridge (HVF - 50 sheet) (1
x 5000)
– 008R12920 Staple cartridge (HVF - 50 sheet) (3
x 5000)
16 008R12964 Staple cartridge (LCSS) (1 x 5000)
– 108R00493 Staple cartridge (LCSS) (3 x 5000)
17 050K21270 Staples (1 x 2000)
– 008R12897 Staples (8 x 2000)
– 008R12941 Staples (3 x 5000)
WARNING
Wear protective gloves when using solvents and
cleaning agents, PL 26.10 Item 5.
To Next Page
