Xerox ColorQube 9303 Series Service Manual

February 2013
6-105
ColorQube® 9303 Family
GP 40
General Procedures/Information
GP 40 Glossary of Terms, Acronyms and Abbreviations
Where possible unit designations as appear in ISO 1000 (International Organization for Stan-
dardization) and Xerox Standard MN2-905 have been used. All measurement appear in ISO
units followed by any conversion in brackets e.g.; 22.5 mm (0.885 inches)
Refer to Table 1.
Table 1 Terms, Acronyms and Abbreviations
Term Description
3TM 3 paper tray module - the base paper system (also call TTM for Three
Tray Module).
Abatement Air system to reduce contaminates on the IOD (Ink On Drum) sensor.
Runs only during print - collects contaminates at bottom of the drum,
before PHs.
ABS Automatic Background Suppression.
ADC Analog to Digital Converter
ADF Automatic Document Feeder
ADU Automatic Duplexing Unit
AGC Automatic Gain Control
AHA Advanced Hardware Architecture
AIF Automated Information Forwarding - sends usage profile to Xerox.
AMCV Average Monthly Copy Volume
AMF Advanced Multi Function device
AMPV Average Monthly Print Volume
AMR Automatic Meter Read
AMS Automatic Magnification Selection
ANSI American National Standards Institute
AP Advanced Purge
API Application Programming Interface
APS Auto Paper Selection
ARP Address Resolution Protocol. Converts an IP address to a MAC address.
See RARP.
ASIC Application Specific Integrated Circuit
ASP Authorized Service Provider
BC Similar to Lakes KIA application
BEUI BIOS Extended User Interface
BIST Built In Self Tests
Bit Depth 1 = Black or white; 4 bit = 16 colours; 8 bits = 256 colours
Bitmap fonts Made of pixels that form the shape of letters. Created in specific sizes
and cannot be resized
Bluetooth Wireless local area network
BM Booklet Maker
BMF Basic Multi Function device
BootP Boot Protocol. AN IP protocol for automatically assigning IP addresses.
BPS Bits Per Second
BT Busy Tone
Burst Mode Copy mode in which two letter / A4 images are on the drum at the same
time - so minimum time to retract / re-engage the Drum stripper / Trans
-
fix.
C Celsius
Calibration
Characterization
Conversion
Colour Management factors: Calibration - turning of the device for opti-
mal performance and maintaining that ‘quality’. Characterization - how
colour gamuts are described for a device. Conversion - how an image is
translated from one device to the next.
CAP Cold Abnormal Purge (temp dropped to low for purging while in standby,
low power or sleep - won’t happen unless a hardware problem.)
CAT Customer Admin Tool
CBC Combined Board Controller (or Common Board Controller) - Linux
based.
CBE Chip Boundary Error - refers to possible mis-read of ink on drum if image
aligns with the chip boundary (every 54 ‘bits’).
CC Copy Centre
CC Copy Controller: controller for input and output and a large portion on the
image path.
CCA Customer Call Assistance
CCD Charged Coupled Device
CCM Copy Controller Module
CCS Copy Control Software - generally used to describe SW crashes in copy
control.
CD Copy Darker. A copy density setting
CDI Common Device Interface
CD-ROM Compact Disk - Read Only Memory
CED Customer Expectations Document - Used by sales/marketing to set Cus-
tomer expectations - how machine will function under various conditions.
CED Customer Expectations Document (quick ref. that customer may sign
stating equipment capabilities and any expectations to normal expecta
-
tions)
CEH&S Corporate Environmental Heath and Safety
CentreWare CentreWare internet services is the embedded HTTP server application
that is available on network enabled machines. It enables access to print
-
ing, faxing and scanning over the internet.
CFR Confirmation To Receive
Chase Sheets A piece of paper that is run through the paper path without receiving an
image. The paper is passed through the roller/drum nip under the same
conditions as for an actual print, except that the drum maintenance cycle
is not performed. The chase sheet is run after a printed image and will
collect untransferred pixels that are left on the drum or transfix roller. The
amount of ink on the chase sheet can be measured to the quantify image
transfer efficiency.
CIE Illuminants Standardize light sources
Table 1 Terms, Acronyms and Abbreviations
Term Description
