Xerox ColorQube 9303 Series Service Manual

February 2013
6-74
ColorQube® 9303 Family
GP 21
General Procedures/Information
Table 1 ColorQube Standalone Digital Copier
Configuration
Machine width (A)
Machine depth
(B)
Moveable install
width required (C)
Fixed install width
required (C)
Moveable install
depth required
(D)
Fixed install
depth required
(D)
Moveable install
airflow / service
workspace (E)
Fixed install
airflow / service
workspace (E)
ColorQube 9301/9302/9303
with OCT
1389 mm (54.7in.) 722 mm
(28.5in.)
2398 mm (94.1in.) 3391 mm (133.5in.) 1829 mm (72in.) 2722 mm
(107in.)
100 mm (4in.) 1000 mm (39.4in.)
ColorQube 9301/9302/9303
with OCT and Tray 5
1607 mm (63.25in.) 722 mm
(28.5in.)
2606 mm (103in.) 3619 mm (142.5in.) 1829 mm (72in.) 2722 mm
(107in.)
100 mm (4in.) 1000 mm (39.4in.)
ColorQube 9301/9302/9303
with 2K LCSS
1651 mm (65in.) 722 mm
(28.5in.)
2642 mm (104in.) 3632 mm (143in.) 1829 mm (72in.) 2722 mm
(107in.)
100 mm (4in.) 1000 mm (39.4in.)
ColorQube 9301/9302/9303
with 2K LCSS and Tray 5
1880 mm (74in.) 722 mm
(28.5in.)
2874 mm
(113.2in.)
3875 mm (152.5in.) 1829 mm (72in.) 2722 mm
(107in.)
100 mm (4in.) 1000 mm (39.4in.)
ColorQube 9301/9302/9303
with HVF
2075 mm (81.7in.) 722 mm
(28.5in.)
3076 mm
(121.1in.)
4077 mm (160.5in.) 1829 mm (72in.) 2722 mm
(107in.)
100 mm (4in.) 1000 mm (39.4in.)
ColorQube9301/9302/9303
with HVF and tray 5
2311 mm (91in.) 722 mm
(28.5in.)
3312 mm
(130.4in.)
4313 mm (169.8in.) 1829 mm (72in.) 2722 mm
(107in.)
100 mm (4in.) 1000 mm (39.4in.)
ColorQube 9301/9302/9303
with HVF BM and tri-fold
2443 mm (96.2in.) 722 mm
(28.5in.)
3444 mm
(135.6in.)
4445 mm (175in.) 1829 mm (72in.) 2722 mm
(107in.)
100 mm (4in.) 1000 mm (39.4in.)
ColorQube 9301/9302/9303
with HVF BM, tri-fold and tray 5
2678 mm
(105.45in.)
722 mm
(28.5in.)
3680 mm
(144.9in.)
4680 mm
(184.25in.)
1829 mm (72in.) 2722 mm
(107in.)
100 mm (4in.) 1000 mm (39.4in.)
