Xerox ColorQube 9303 Series Service Manual

February 2013
6-108
ColorQube® 9303 Family
GP 40
General Procedures/Information
FAX Facsimile
FCC Federal Communications Commission
FCD Facsimile Coded Data
FCS Facsimile Checking Sequence
FCOT First Copy Out Time
FD Functional Description
FDI Foreign Device Interface
FIFO First In First Out
FireWire IEEE 1349. High speed serial communications system, comprising hard-
ware plus protocol. Operates at 100, 200 or 400 Mbits/s, with 800 Mbits/s
under development. See USB and RS-232
Firmware Software in a ROM
FLASH On board erasable and re programmable non volatile memory
FLUSH Flush routine to purge contaminated ink reservoir, via multiple purges - if
there is too much mixing the may take over an hour to fully purger reser
-
voirs and PHs, approximately 1 stick of each colour.
FMEA Failure Modes and Effects Analysis
FOIP FAX Over Internet Protocol
Foldability Refers to how well a print withstands folding
FPGA Field Programmable Gate Array
FPOT First Print Out Time
Freckle / Freckling A pixel from a previous image that shows up on the next image, usually
left from the drum cleaning.
FRU Field Replacement Unit
FSK Frequency Shift Keying
FSMA Field Service Maintenance Agreement
FTP File Transfer Protocol
FTTR Fast Time to Ready - allows running paper through machine without print
head use.
FWA Full Width Array
FX Fuji Xerox
Gamut Range of colours that a device can reproduce, the larger the better. RGB
gamut is larger than CMYK
Garfield IME simulates a function i.e. paperless pump. IME does not contain a
MU, IOD or abatement plenum etc.
GCR Grey Component Replacement. Black replace greys that would other-
wise be created using all three CMYK colours.
GDI Graphical Display Interface
GEL Gel (oil and ink mixture) that is removed from the drum by the metering
blade.
Ghosting A print quality artifact where a previous image can be seen on the current
image.
GIS Global Imaging Systems
GLCD Graphic Liquid Crystal Display
Table 1 Terms, Acronyms and Abbreviations
Term Description
Gloss Variance Mainly duplex - especially at very low usage rates.
GND Ground
GPD Minidrivers A Generic Printer Description file has a function similar to PPD files. This
format was developed by Microsoft to provide a simple method to
develop drivers for non-postScript printers. Standard GPD mini drivers
share the same lamentations as the PPD mini drivers, but they too can
be enhanced using plug-ins. GPD Mini drivers are a new technology
introduced for Windows 2000 and they will also be supported Windows
NT 4. In Windows 95/98, a similar, but less powerful ‘unidriver’ format
was used.
GS German safety
GSM Grams per square metre
GUI Graphics User Interface
H2H Head to Head alignment
HAM Head Alignment Machine - used to align print heads on the SWFA
HAU Head Adjustment Uniformity (refers to printhead NVM data)
HAY Head Adjustment Y delay (refers to printhead NVM data)
HC High Capacity
HCD Head Configuration Data. Written during manufacture, read at switch on.
Failure prevents machine operation.
HCF High Capacity Feeder
HCSS High Capacity Stapler Stacker (3K)
HCSS BM High Capacity Stapler Stacker Booklet Maker
HDD Hard Disk Drive
Head to head uni-
formity
Measure relative intensity between heads at 100% area coverage. If
needed, will adjust head voltage or norm clicks for improvement.
HDLC High Level Data Link Control
HFC Head Field Corrections. Log file of manual and automatic HAU correc-
tions. Failure has no customer impact.
HFD Head Field Data
HFLEN High - Frequency (random) Line - Edge Noise. image quality metric.
HFSI High Frequency Service Intervals
HLD High Level Design. A document that defines the software high level
design.
HM Head Maintenance
HSL Hue, Saturation and Lightness chart (tristimulus colour space)
HTD Head to drum spacing (critical specification) - also used to name the
sandwich frames of the engine block since it sets the drum and the PH
stop points of reference.
HTTP Hyper Text Transfer Protocol
Hue Basic colour such as red, pink, blue or orange (determined by wave-
length). White, black and grey are not considered to have ‘hue’ and are
considered ‘neutral’ colours.
HUI Hybrid User Interface
Table 1 Terms, Acronyms and Abbreviations
Term Description
