Spare Parts List
Phaser 3200MFP / Workcentre PE220 04/07 5-3
PL 1 Main Assembly (Workcentre PE220)
Item Part Number Description Qt’y Remark
0 SET
1 ELA HOU-FRAME LOWER (REFER TO PL 8.0
)1
2 122N00243 UNIT-LSU 1
3 CBF HARNESS-LSU 1
4 INITIAL(1K) TONER CARTRIDGE 1
5 101N01380 FUSER_110V (REFER TO PL 7.0
)1
5 101N01381 FUSER_220V (REFER TO PL 7.0
)1
6 SHEILD-P-ENGINE 1
7 GROUND-P-HVPS 2
8 105N02066 SMPS 110V 1
8 105N02067 SMPS 220V 1
9 140N63039 PBA SUB-LIU WESTERN EUROPE 1
9 140N63038 PBA SUB-LIU US/CANADA/SAUDI ARABIA/RUSSIA... 1
10 CBF HARNESS HVPS 1
11 HARNESS CLAMP 1
12 CBF HARNESS LIU 1
13 116N00244 ELA UNIT-TERMINAL TR L 5
13-1 SPRING ETC-HV LARGE 1
13-2 ICT-SHAFT HV LARGE 1
14 015N00557 PLATE-P-CHANNEL 1
15 105N02068 HVPS 1
16 NOT USED
17 BRACKET-P-MAIN BOARD 1
18 117N01691 GROUND-P-MAIN BOARD 1
19 030N00711 BRACKET-P-PORT 1
20 140N63040 PBA MAIN 1
21 ELA HOU-FULL SENSOR HARNESS 1
22 002N02429 COVER-M-SIDE R 1
23 002N02430 ELA HOU-COVER SIDE L 1
23-1 002N02431 COVER-M-SIDE L 1
23-2 130N01412 SPEAKER 1
23-3 IPR-UNIT FIXING BRACKET 1
24 002N02432 MEA-COVER FRONT 1
24-1 COVER-M-FRONT 1
24-2 050N00480 TRAY-M-CASSETTE 1
24-3 TRAY-M-EXTENSION LARGE 1
24-4 TRAY-M-EXTENSION SMALL 1
25 002N02433 ELA HOU-COVER MIDDLE 1
25-1 COVER-M-MIDDLE 1
25-2 PMO-M-STACKER 1
25-3 SHEET-FAN 1
26 002N02435 MEA UNIT-COVER REAR 1
26-1 COVER-M-REAR 1
26-2 MEA UNIT-COVER JAM 1
26-2-1 COVER-M-JAM 1
26-2-2 COVER-M-JAM DUMMY 1
27 002N02435
ELA HOU-SCAN (ALSO REFER TO PL 2.0
, PL 3.0 & PL 4.0)
1
27-1 021N02251 CAP-M-HINGE 2
28
MEA UNIT-MP TRAY (REFER TO
PL 9.0)
1
29 AC POWER CORD (US VER.) (REFER TO PL 10.0
)1
30 USB CABLE (REFER TO PL 10.0
)1
31 TELEPHONE LINE CORD (US VER.) (REFER TO PL 10.0
)1
To Next Page
