Xerox Phaser 3200MFP Service Manual

Status Indicator RAPs
Phaser 3200MFP / Workcentre PE220 04/07 2-11
5 Multi-Feeding RAP
Description
Multiple sheets of paper are fed together.
Check and Cause Solution
1. Bad quality paper. 1. Fan the paper. Recommend the use of
good quality paper.
2. Pad-Friction is contaminated. 2. Clean the pad friction with soft cloth, damp-
ened with IPA (Isopropyl Alcohol).
3. Solenoid malfunction (the solenoid does
not work properly): Perform Engine Test
Mode, GP 6 - Pick up Test.
3. Check and install a new solenoid if neces-
sary:
- PL 6.0 (Workcentre PE220)
- PL 6.1 (Phaser 3200)

Xerox Phaser 3200MFP Specifications

General

Print Technology	Laser
Functions	Print, Copy, Scan, Fax
Print Resolution	Up to 600 x 600 dpi
First Page Out Time	Less than 10 seconds
Copy Resolution	Up to 600 x 600 dpi
Maximum Copy Count	99 copies
Fax Transmission Speed	33.6 kbps
Standard Paper Capacity	250 sheets
Connectivity	USB 2.0
Memory	32 MB
Operating System Compatibility	Windows, Mac OS
Duplex Printing	Manual
Scan Type	Flatbed
Media Sizes Supported	Letter, Legal, Executive, A4, A5
Media Weight	60 to 163 g/m²
Monthly Duty Cycle	10, 000 pages
Toner Yield	Up to 3, 000 pages
