Xerox Phaser 3200MFP - Faulty Motor RAP

Status Indicator RAPs
2-20 04/07 Phaser 3200MFP / Workcentre PE220
12 Faulty Motor RAP
WARNING
Switch off the electricity to the machine. Disconnect the power cord from the customer supply
while performing tasks that do not need electricity. Electricity can cause death or injury. Moving
parts can cause injury.
Description
The main motor is not working during printing. Therefore, paper does not feed into the printer, re-
sulting 'Jam 0'.
Check and Cause Solution
1. The main motor may be defective. 1. Check the operation using Engine Test
Mode, GP 6.
Check and install new parts as necessary:
• Main drive assembly,
- PL 8.0 (Workcentre PE220)
- PL 8.1 (Phaser 3200)
• Main PBA
- PL 1.0 (Workcentre PE220)
- PL 1.1 (Phaser 3200)
