Xerox Phaser 3200MFP Service Manual

Image Quality
Phaser 3200MFP / Workcentre PE220 04/07 3-11
IQ 9 Ghost (1)
Description
Ghost occurs at 75.5 mm intervals of the OPC drum on the print.
Check and Cause Solution
1. Bad contacts caused by contamina-
tion from toner particles between high
voltage terminal in the main body and
the electrode of the Developer.
1. Clean the terminals.
- PL 1.0
(Workcentre PE220)
- PL 1.1
(Phaser 3200)
2. The life of developer is expired. 2. Install a new toner cartridge:
- PL 1.0
(Workcentre PE220)
- PL 1.1
(Phaser 3200)
3. Transfer roller lifetime (50.000
sheets) has expired.
3. Check the life of the transfer
roller.
Check and install a new transfer
roller if necessary:
- PL 6.0
(Workcentre PE220)
- PL 8.1
(Phaser 3200).
4. Abnormal low temperature (below
10°C).
4. Wait about 30 minutes after
power on before using the machine.
5. Bad contacts caused by contamina-
tion from toner particles between high
voltage terminal in the main body and
the one in the HVPS board.
5. Check and install new parts as
necessary:
• Main PBA
- PL 1.0
(Workcentre PE220)
- PL 1.1
(Phaser 3200)
•HVPS
- PL 1.0
(Workcentre PE220)
- PL 1.1
(Phaser 3200)

Xerox Phaser 3200MFP Specifications

General

Print Technology	Laser
Functions	Print, Copy, Scan, Fax
Print Resolution	Up to 600 x 600 dpi
First Page Out Time	Less than 10 seconds
Copy Resolution	Up to 600 x 600 dpi
Maximum Copy Count	99 copies
Fax Transmission Speed	33.6 kbps
Standard Paper Capacity	250 sheets
Connectivity	USB 2.0
Memory	32 MB
Operating System Compatibility	Windows, Mac OS
Duplex Printing	Manual
Scan Type	Flatbed
Media Sizes Supported	Letter, Legal, Executive, A4, A5
Media Weight	60 to 163 g/m²
Monthly Duty Cycle	10, 000 pages
Toner Yield	Up to 3, 000 pages
