Xerox Phaser 3200MFP Service Manual

Status Indicator RAPs
Phaser 3200MFP / Workcentre PE220 04/07 2-15
9 Melting Fuser Gear RAP
WARNING
Switch off the electricity to the machine. Disconnect the power cord from the customer supply
while performing tasks that do not need electricity. Electricity can cause death or injury. Moving
parts can cause injury.
Description
The fuser gear has melted.
Check and Cause Solution
1. Check the following parts:
•Heat lamp
- PL 7.0 (Workcentre PE220)
- PL 7.1 (Phaser 3200)
• Thermostat
- PL 7.0 (Workcentre PE220)
- PL 7.1 (Phaser 3200)
•Thermistor
- PL 7.0 (Workcentre PE220)
- PL 7.1 (Phaser 3200)
1. Perform Engine Test Mode to test the
Fuser - THERM ADC 120, GP 6.
Check and install new parts as necessary:
• Halogen lamp
- PL 7.0 (Workcentre PE220)
- PL 7.1 (Phaser 3200)
• Fuser assembly
- PL 7.0 (Workcentre PE220)
- PL 7.1 (Phaser 3200)
•SMPS
- PL 1.0 (Workcentre PE220)
- PL 1.1 (Phaser 3200)
• Main PBA
- PL 1.0 (Workcentre PE220)
- PL 1.1 (Phaser 3200)

Xerox Phaser 3200MFP Specifications

General

Print Technology	Laser
Functions	Print, Copy, Scan, Fax
Print Resolution	Up to 600 x 600 dpi
First Page Out Time	Less than 10 seconds
Copy Resolution	Up to 600 x 600 dpi
Maximum Copy Count	99 copies
Fax Transmission Speed	33.6 kbps
Standard Paper Capacity	250 sheets
Connectivity	USB 2.0
Memory	32 MB
Operating System Compatibility	Windows, Mac OS
Duplex Printing	Manual
Scan Type	Flatbed
Media Sizes Supported	Letter, Legal, Executive, A4, A5
Media Weight	60 to 163 g/m²
Monthly Duty Cycle	10, 000 pages
Toner Yield	Up to 3, 000 pages
