Xerox Phaser 3200MFP Service Manual

Status Indicator RAPs
2-16 04/07 Phaser 3200MFP / Workcentre PE220
10 Paper Empty RAP
10A Paper empty with indication error RAP
Description
Paper Empty is displayed in the LCD panel even when paper is loaded in the cassette.
The paper empty message does not appear in the LCD when the paper cassette is empty.
Check and Cause Solution
1. Faulty cables or connectors. 1. Check the cables and connectors.
2. The paper empty sensor actuator is defect-
ective.
2. Check and install a new paper empty sen-
sor actuator:
- PL 8.0 (Workcentre PE220)
- PL 8.1 (Phaser 3200)
3. Memory error. 3. Perform clear all memory, GP 3.
4. The SMPS PBA or Main PBA is defective. 4. Check and install new parts as necessary:
• SMPS PBA
- PL 1.0 (Workcentre PE220)
- PL 1.1 (Phaser 3200)
• Main PBA
- PL 1.0 (Workcentre PE220)
- PL 1.1 (Phaser 3200)

Xerox Phaser 3200MFP Specifications

General

Print Technology	Laser
Functions	Print, Copy, Scan, Fax
Print Resolution	Up to 600 x 600 dpi
First Page Out Time	Less than 10 seconds
Copy Resolution	Up to 600 x 600 dpi
Maximum Copy Count	99 copies
Fax Transmission Speed	33.6 kbps
Standard Paper Capacity	250 sheets
Connectivity	USB 2.0
Memory	32 MB
Operating System Compatibility	Windows, Mac OS
Duplex Printing	Manual
Scan Type	Flatbed
Media Sizes Supported	Letter, Legal, Executive, A4, A5
Media Weight	60 to 163 g/m²
Monthly Duty Cycle	10, 000 pages
Toner Yield	Up to 3, 000 pages
