3 JAM 1 RAP
Description
Paper is jammed in front of or inside the fuser.
Paper is jammed in the discharge roller and in the fuser after passing through the Actuator-Feed.
Check and Cause Solution
1. Check for small pieces of paper jammed in
the fuser.
1. Clear paper from the fuser:
- PL 7.0 (Workcentre PE220)
- PL 7.1 (Phaser 3200)
2. If paper is jammed in the discharge roller
and the fuser just after passing through the
Actuator Feed.
2. Check the feed sensor actuator for dam-
age:
- PL 6.0 (Workcentre PE220)
- PL 6.1 (Phaser 3200)
3.Paper is jammed in front of or inside the
fuser.
3. Check and install a new SMPS if neces-
sary:
- PL 1.0 (Workcentre PE220)
- PL 1.1 (Phaser 3200)
