Xerox Phaser 3200MFP Service Manual

Status Indicator RAPs
Phaser 3200MFP / Workcentre PE220 04/07 2-21
13 No Power RAP
Description
When system power is turned on the LCD panel does not come on.
Check and Cause Solution
1. Check if the power input and SMPS output
are normal.
1. Check and install new parts as necessary:
• Power supply cord
- PL 1.0 (Workcentre PE220)
- PL 1.1 (Phaser 3200)
•SMPS
- PL 1.0 (Workcentre PE220)
- PL 1.1 (Phaser 3200)
2. LCD panel does not come on but normal
start up sounds are heard.
2. Check and install a new OPE unit, PL 5.0
3. The OPE unit display does not come on
and no start up sounds are heard.
3. Check and install a new Main PBA if neces-
sary:
- PL 1.0 (Workcentre PE220)
- PL 1.1 (Phaser 3200)

Xerox Phaser 3200MFP Specifications

General

Print Technology	Laser
Functions	Print, Copy, Scan, Fax
Print Resolution	Up to 600 x 600 dpi
First Page Out Time	Less than 10 seconds
Copy Resolution	Up to 600 x 600 dpi
Maximum Copy Count	99 copies
Fax Transmission Speed	33.6 kbps
Standard Paper Capacity	250 sheets
Connectivity	USB 2.0
Memory	32 MB
Operating System Compatibility	Windows, Mac OS
Duplex Printing	Manual
Scan Type	Flatbed
Media Sizes Supported	Letter, Legal, Executive, A4, A5
Media Weight	60 to 163 g/m²
Monthly Duty Cycle	10, 000 pages
Toner Yield	Up to 3, 000 pages
