Xerox Phaser 3200MFP Service Manual

Image Quality
3-20 04/07 Phaser 3200MFP / Workcentre PE220
IQ 18 Printed Vertical Lines Not Straight
Description
When printing, vertical lines are not straight.
Check and Cause Solution
1. Check stability of 24V supply to LSU. 1. 24V stable - check and install a new LSU if neces-
sary:
- PL 1.0
(Workcentre PE220)
- PL 1.1
(Phaser 3200) is necessary
24V unstable - check and install a new SMPS if neces-
sary:
- PL 1.0
(Workcentre PE220)
- PL 1.1
(Phaser 3200)
If the problem persists, install a new main PBA:
- PL 1.0
(Workcentre PE220)
- PL 1.1
(Phaser 3200)

Xerox Phaser 3200MFP Specifications

General

Print Technology	Laser
Functions	Print, Copy, Scan, Fax
Print Resolution	Up to 600 x 600 dpi
First Page Out Time	Less than 10 seconds
Copy Resolution	Up to 600 x 600 dpi
Maximum Copy Count	99 copies
Fax Transmission Speed	33.6 kbps
Standard Paper Capacity	250 sheets
Connectivity	USB 2.0
Memory	32 MB
Operating System Compatibility	Windows, Mac OS
Duplex Printing	Manual
Scan Type	Flatbed
Media Sizes Supported	Letter, Legal, Executive, A4, A5
Media Weight	60 to 163 g/m²
Monthly Duty Cycle	10, 000 pages
Toner Yield	Up to 3, 000 pages
