Xerox Phaser 3200MFP Service Manual

Status Indicator RAPs
2-12 04/07 Phaser 3200MFP / Workcentre PE220
6 Fuser Jam RAP
Description
Constant Jam where paper is entering Fuser unit.
Fuser rollers do not turn.
Check and Cause Solution
1. The fuser stripper fingers are misaligned 1. Check the stripper fingers:
- PL 7.0 (Workcentre PE220)
- PL 7.1 (Phaser 3200).
2. Check if the fuser has overheated and
melted the fuser gear. Check for heat damage
to the heat roller and pressure roller:
- PL 7.0 (Workcentre PE220)
- PL 7.1 (Phaser 3200)
2. Check the following parts:
• Heat Lamp
- PL 7.0 (Workcentre PE220)
- PL 7.1 (Phaser 3200)
• Thermostat
- PL 7.0 (Workcentre PE220)
- PL 7.1 (Phaser 3200)
•Thermistor
- PL 7.0 (Workcentre PE220)
- PL 7.1 (Phaser 3200)
Perform Engine Test Mode - THERM ADC
120, GP 6.
Check and install new parts as necessary:
•SMPS
- PL 1.0 (Workcentre PE220)
- PL 1.1 (Phaser 3200)
• Main PBA
- PL 1.0 (Workcentre PE220)
- PL 1.1 (Phaser 3200)
•Fuser
- PL 7.0 (Workcentre PE220)
- PL 7.1 (Phaser 3200)

Xerox Phaser 3200MFP Specifications

General

Print Technology	Laser
Functions	Print, Copy, Scan, Fax
Print Resolution	Up to 600 x 600 dpi
First Page Out Time	Less than 10 seconds
Copy Resolution	Up to 600 x 600 dpi
Maximum Copy Count	99 copies
Fax Transmission Speed	33.6 kbps
Standard Paper Capacity	250 sheets
Connectivity	USB 2.0
Memory	32 MB
Operating System Compatibility	Windows, Mac OS
Duplex Printing	Manual
Scan Type	Flatbed
Media Sizes Supported	Letter, Legal, Executive, A4, A5
Media Weight	60 to 163 g/m²
Monthly Duty Cycle	10, 000 pages
Toner Yield	Up to 3, 000 pages
