Xerox Phaser 3200MFP Service Manual

Image Quality
3-10 04/07 Phaser 3200MFP / Workcentre PE220
IQ 8 Background
Description
Light dark background on the print.
Check and Cause Solution
1. Has the customer been making a
lot of prints at less than 2% area
coverage?
Note: The print cartridge is basi-
cally designed to print 3,000 sheets
with 5% image.
1. Inform the customer that low
area coverage will cause back-
ground problems.
2. Is recycled paper being used? 2. Image quality is not guaranteed if
recycle paper is used.
3. Has the life span of the devel-
oper ended?
3. Install a new toner cartridge:
- PL 1.0
(Workcentre PE220)
- PL 1.1
(Phaser 3200)
4. Is the movement (Up and Down)
of the transfer roller smooth?
4. Clean the bushings on the trans-
fer roller:
- PL 6.0
(Workcentre PE220)
- PL 6.1
(Phaser 3200)
5. The HVPS may be defective. 5. If the problem is still present,
check and install new parts as nec-
essary:
• Toner cartridge
- PL 1.0
(Workcentre PE220)
- PL 1.1
(Phaser 3200)
•HVPS
- PL 1.0
(Workcentre PE220)
- PL 1.1
(Phaser 3200)

Xerox Phaser 3200MFP Specifications

General

Print Technology	Laser
Functions	Print, Copy, Scan, Fax
Print Resolution	Up to 600 x 600 dpi
First Page Out Time	Less than 10 seconds
Copy Resolution	Up to 600 x 600 dpi
Maximum Copy Count	99 copies
Fax Transmission Speed	33.6 kbps
Standard Paper Capacity	250 sheets
Connectivity	USB 2.0
Memory	32 MB
Operating System Compatibility	Windows, Mac OS
Duplex Printing	Manual
Scan Type	Flatbed
Media Sizes Supported	Letter, Legal, Executive, A4, A5
Media Weight	60 to 163 g/m²
Monthly Duty Cycle	10, 000 pages
Toner Yield	Up to 3, 000 pages
