Xerox Phaser 3200MFP Service Manual

Status Indicator RAPs
2-32 04/07 Phaser 3200MFP / Workcentre PE220
19 Scanning RAP
19A PC Scanning Problems
Description
Unable to scan using a PC.
19B Poor Quality of PC Scanned images
Description
Poor quality of scanned to PC images.
Check and Cause Solution
1. Check the Cable (USB or Parallel) is prop-
erly connected and that the machine can print
correctly.
1. Reconnect the PC and machine, replace
any faulty cables. If using a parallel cable,
check that the parallel port is properly config-
ured. Ask the customer to check the BIOS of
the PC to ensure that there are no IRQ con-
flicts and to check that the input/output range
is 0378.
2. Check that the driver is installed properly. 2. If printing is OK check that the Scan driver
is also installed (Refer to User's Manual.)
3. Check that the copy function operates nor-
mally.
3. Check and install new parts as necessary:
• Main PBA
- PL 1.0 (Workcentre PE220)
- PL 1.1 (Phaser 3200) and
• CIS, PL 4
Check and Cause Solution
1. Check if the resolution is set too low in PC
Scan options. (Refer to the User Manual.)
1. Teach the user about scanner resolution –
refer to the User Guide.
2. Use TECH mode, GP 4, to carry out a
shading test and examine the waveform print-
out.
2. If the CIS waveform form is abnormal,
check and install a new CIS, PL 4 if neces-
sary.

Xerox Phaser 3200MFP Specifications

General

Print Technology	Laser
Functions	Print, Copy, Scan, Fax
Print Resolution	Up to 600 x 600 dpi
First Page Out Time	Less than 10 seconds
Copy Resolution	Up to 600 x 600 dpi
Maximum Copy Count	99 copies
Fax Transmission Speed	33.6 kbps
Standard Paper Capacity	250 sheets
Connectivity	USB 2.0
Memory	32 MB
Operating System Compatibility	Windows, Mac OS
Duplex Printing	Manual
Scan Type	Flatbed
Media Sizes Supported	Letter, Legal, Executive, A4, A5
Media Weight	60 to 163 g/m²
Monthly Duty Cycle	10, 000 pages
Toner Yield	Up to 3, 000 pages
