Xerox Phaser 3200MFP Service Manual

Status Indicator RAPs
2-14 04/07 Phaser 3200MFP / Workcentre PE220
8 Control Panel RAP
8A LCD Defect
Description
Strange characters are displayed in the LCD Window and OPE Panel keys do not work.
8B Defective OPE Keypad
Description
Pressing keys does not cause the set to respond correctly.
Check and Cause Solution
1. Clear the memory, GP 3. 1. Restart the machine and try again after
clearing the memory.
2. Ensure the OPE HARNESS is connected
to the Connection Board.
2. Check and install new parts as necessary:
• OPE Unit, PL 5.0
• Main PBA
- PL 1.0 (Workcentre PE220)
- PL 1.1 (Phaser 3200)
Check and Cause Solution
1. Clear the memory, GP 3 and restart the
machine.
1. Check and replace new parts as necessary
• Membrane, PL 5.0
• Keypad assembly, PL 5.0
2. Check if there is an audible clicking sound
when a key is pressed.
2. Check and install new parts as necessary:
• OPE assembly, PL 5.0
• Main PBA
- PL 1.0 (Workcentre PE220)
- PL 1.1 (Phaser 3200).

Xerox Phaser 3200MFP Specifications

General

Print Technology	Laser
Functions	Print, Copy, Scan, Fax
Print Resolution	Up to 600 x 600 dpi
First Page Out Time	Less than 10 seconds
Copy Resolution	Up to 600 x 600 dpi
Maximum Copy Count	99 copies
Fax Transmission Speed	33.6 kbps
Standard Paper Capacity	250 sheets
Connectivity	USB 2.0
Memory	32 MB
Operating System Compatibility	Windows, Mac OS
Duplex Printing	Manual
Scan Type	Flatbed
Media Sizes Supported	Letter, Legal, Executive, A4, A5
Media Weight	60 to 163 g/m²
Monthly Duty Cycle	10, 000 pages
Toner Yield	Up to 3, 000 pages
