Xerox Phaser 3200MFP Service Manual

Image Quality
Phaser 3200MFP / Workcentre PE220 04/07 3-7
IQ 5 Light Image
Description
The printed image is light, with no ghost.
Check and Cause Solution
1. Ambient temperature is below
than 10°C.
1. Wait 30 minutes after printer is
powered on before you start print-
ing.
2. Check shading profile. 2. Redo shading profile in the Tech
mode, GP 4
.
3. Bad contact caused by the toner
contamination between the high
voltage terminal in the HVPS and
the one in the set.
3. Clean the contaminated area.
4. Develop roller is contaminated
when the toner cartridge is almost
consumed.
4. Install a new toner cartridge:
- PL 1.0
(Workcentre PE220)
- PL 1.1
(Phaser 3200).
5. Abnormal output from the HVPS
can be caused by contamination
5. Check and install a new HVPS If
necessary:
- PL 1.0
(Workcentre PE220)
- PL 1.1
(Phaser 3200).
