Status Indicator RAPs
Phaser 3200MFP / Workcentre PE220 04/07 2-7
5. If the paper feeds into the machine and
Jam 0 occurs, perform Engine Test Mode,
GP 6 - Feed Sensor Test.
5. Check and install new parts as necessary:
• Feed sensor actuator,
- PL 6.0 (Workcentre PE220)
- PL 6.1 (Phaser 3200).
•SMPS
- PL 1.0 (Workcentre PE220)
- PL 1.1 (Phaser 3200)
• HVPS
- PL 1.0 (Workcentre PE220)
- PL 1.1 (Phaser 3200)
Check and Cause Solution
