Xerox Phaser 3200MFP Service Manual

Spare Parts List
Phaser 3200MFP / Workcentre PE220 04/07 5-5
PL 1.1 Main Assembly (Phaser 3200)
Item Part Number Description Qt’y Remark
0 SET
1 ELA HOU-FRAME LOWER (REFER TO PL 8.1
)1
2 122N00272 UNIT-LSU 1
3 CBF HARNESS-LSU 1
4 INITIAL(1K) PRINT CARTRIDGE 1
5 140N63272 FUSER_110V (REFER TO PL 7.1
)1
5 140N63273 FUSER_220V (REFER TO PL 7.1
)1
6 SHEILD-P-ENGINE 1
7 GROUND-P-HVPS 2
8 140N63278 SMPS 110V 1
8 140N63273 SMPS 220V 1
9 140N63189 PBA SUB-LIU WESTERN EUROPE 1
9 140N63190 PBA SUB-LIU US/CANADA/SAUDI ARABIA/RUSSIA 1
10 LIU HARNESS 1
11 BOARD SUPPORT 1
12 CABLE CLAMP 1
13 CABLE CLAMP
14 FAN-DC
15 CBF HARNESS GROUND
16 116N00244 ELA UNIT-TERMINAL TR L 5
16-1 ICT-SHAFT HV LARGE 1
16-2 SPRING ETC-HV LARGE 1
17
18 105N02138 HVPS 1
19 HVPS SHEET
20 PBA SHIELD
21 140N63270 MAIN PBA (PHASER 3200MFP/B)
21 140N63271 MAIN PBA (PHASER 3200MFP/N)
22 CBF HARNESS-THERMISTOR
23 HARNESS SENSOR-JOINT
24 COVER ASSEMBLY (REFER TO PL 1.2
)
25 MEA UNIT-MP TRAY (REFER TO PL 9.0
)
26 002N02696
ELA HOU-SCAN (REFER TO PL 2.0
, PL 3.0 & PL 4.0)
26-1 CAP-M-HINGE
27 002N02697 PAPER COVER
28 CBF-POWER CORD (REFER TO PL 10.0
)
28 CBF-POWER CORD (REFER TO PL 10.0
)
29 PLASTIC FOOT

Xerox Phaser 3200MFP Specifications

General

Print Technology	Laser
Functions	Print, Copy, Scan, Fax
Print Resolution	Up to 600 x 600 dpi
First Page Out Time	Less than 10 seconds
Copy Resolution	Up to 600 x 600 dpi
Maximum Copy Count	99 copies
Fax Transmission Speed	33.6 kbps
Standard Paper Capacity	250 sheets
Connectivity	USB 2.0
Memory	32 MB
Operating System Compatibility	Windows, Mac OS
Duplex Printing	Manual
Scan Type	Flatbed
Media Sizes Supported	Letter, Legal, Executive, A4, A5
Media Weight	60 to 163 g/m²
Monthly Duty Cycle	10, 000 pages
Toner Yield	Up to 3, 000 pages
