Xerox Phaser 3200MFP Service Manual

Spare Parts List
Phaser 3200MFP / Workcentre PE220 04/07 5-15
PL 3.0 Platen Cover Assembly
Item Part Number Description Qt’y Remark
0 002N02448 MEA-COVER PLATEN 1
1 002N02436 COVER-M-PLATEN 1
2 095N00274 SHEET-WHITE SPONGE 1
3 038N00405 PMO-TX STACKER 1
4 038N00410 PMO-DOC GUIDE (R) 1
5 038N00406 PMO-DOC GUIDE (L) 1
6 028N00321 IPR-WASHER SPRING CU 2
7 007N01178 GEAR-PINION 1
8 009N01514 SPRING ETC-FEED 6
9 SHAFT PINCH 1
10 022N02014 PMO-ROLL PINCH 2
11 SHAFT-IDLE FEED 2
12 022N02019 RPR-ROLLER EXIT IDLE 2
13 050N00479 MEA-TX STACKER 1

Xerox Phaser 3200MFP Specifications

General

Print Technology	Laser
Functions	Print, Copy, Scan, Fax
Print Resolution	Up to 600 x 600 dpi
First Page Out Time	Less than 10 seconds
Copy Resolution	Up to 600 x 600 dpi
Maximum Copy Count	99 copies
Fax Transmission Speed	33.6 kbps
Standard Paper Capacity	250 sheets
Connectivity	USB 2.0
Memory	32 MB
Operating System Compatibility	Windows, Mac OS
Duplex Printing	Manual
Scan Type	Flatbed
Media Sizes Supported	Letter, Legal, Executive, A4, A5
Media Weight	60 to 163 g/m²
Monthly Duty Cycle	10, 000 pages
Toner Yield	Up to 3, 000 pages
