Xerox Phaser 3200MFP Service Manual

Spare Parts List
Phaser 3200MFP / Workcentre PE220 04/07 5-19
PL 5.0 OPE Unit
Item Part Number Description Qt’y Remark
0 002N02442 ELA HOU-OPE (WORKCENTRE PE220) 1
0 002N02699 ELA HOU-OPE (PHASER 3200) 1
1 002N02437 COVER-M-OPE 1
2 110N01390 RUBBER-TEL 1
3 110N01391 RUBBER-SCROLL 1
4 140N63042 PBA SUB-OPE 1
5 003N00972 KEY-M_SHIFT 1
6 029N00367 KEY-M_STATUS 1
7 003N00969 KEY-M_TEL_R2_XRX 1
8 003N00893 KEY-M-STOP 1
9 003N00970 KEY-M_START_XRX 1
10 029N00368 KEY-M_FAX 1
11 029N00380 KEY-M_SCROLL_R2X 1
12 152N11627 CBF HARNESS-OPE 1
13 LCD DISPLAY 1
14 002N02421 SHEET-OVERLAY ENGLISH (WORKCENTRE PE220) 1
14 002N02422 SHEET-OVERLAY SPANISH (WORKCENTRE PE220) 1
14 002N02423 SHEET-OVERLAY BRAZILIAN PORTUGUESE (WORKCENTRE
PE220)
1
14 002N02424 SHEET-OVERLAY FRENCH (WORKCENTRE PE220) 1
14 002N02425 SHEET-OVERLAY RUSSIAN (WORKCENTRE PE220) 1
14 SHEET-OVERLAY ENGLISH (PHASER 3200) 1
14 SHEET-OVERLAY SPANISH (PHASER 3200) 1
14 SHEET-OVERLAY FRENCH (PHASER 3200) 1

Xerox Phaser 3200MFP Specifications

General

Print Technology	Laser
Functions	Print, Copy, Scan, Fax
Print Resolution	Up to 600 x 600 dpi
First Page Out Time	Less than 10 seconds
Copy Resolution	Up to 600 x 600 dpi
Maximum Copy Count	99 copies
Fax Transmission Speed	33.6 kbps
Standard Paper Capacity	250 sheets
Connectivity	USB 2.0
Memory	32 MB
Operating System Compatibility	Windows, Mac OS
Duplex Printing	Manual
Scan Type	Flatbed
Media Sizes Supported	Letter, Legal, Executive, A4, A5
Media Weight	60 to 163 g/m²
Monthly Duty Cycle	10, 000 pages
Toner Yield	Up to 3, 000 pages
