Xerox Phaser 3200MFP Service Manual

Spare Parts List
Phaser 3200MFP / Workcentre PE220 04/07 5-21
PL 6.0 Paper Path Assembly (Workcentre PE220)
Item Part Number Description Qt’y Remark
0 PAPER-PATH ASSEM 1
1 038N00463 GUIDE-M-PAPER PATH 1
2 130N01408 FEED SENSOR ACTUATOR 1
3 009N01519 SPRING ETC-LEVER SENSOR 1
4 015N00558 IPR-PLATE SAW 1
5 NOT USED
6 GROUND-P-ZENER 1
7 GROUND-P-THV 1
8 GROUND-P-SAW 1
9 019N00841 MEA UNIT-HOLDER_PAD 1
9-1 009N01520 SPRING ETC-EXIT ROLL FD 2
9-2 019N00836 PAD-FRICTION 1
9-3 019N00837 HOLDER-M-PAD 1
10 LEVER-M-KICKER P/U 2
11 130N01419 MEA UNIT-PICK UP GEAR 1
11-1 GEAR-PICK_UP B 1
11-2 GEAR-PICK_UP A 1
11-3 SPRING-CS 1
12 121N01078 SOLENOID 1
13 007N01375 GEAR-FEED 35/19 1
14 016N00261 BUSH-M-TR L 1
15 016N00281 PMO-BUSHING_TR(L) 1
16 009N01521 SPRING ETC-TR(12) 2
17 022N02126 TRANSFER ROLLER 1
18 019N00838 HOLDER-PTL 1
19 IPR-P-EARTH TRANSFER 1
20 SHAFT-P-PICK_UP 1
21 130N01424 MEA UNIT PICK_UP 1
21-1 HOUSING-M-PICK_UP B 1
21-2 HOUSING-M-PICK_U 1
21-3 130N01416 PICK UP RUBBER 1
22 130N01410 CAM-M-PICK_UP 2
23 007N01376 GEAR-TRANSFER 1
24 BRACKET-P-BAR_PICK_UP 1

Xerox Phaser 3200MFP Specifications

General

Print Technology	Laser
Functions	Print, Copy, Scan, Fax
Print Resolution	Up to 600 x 600 dpi
First Page Out Time	Less than 10 seconds
Copy Resolution	Up to 600 x 600 dpi
Maximum Copy Count	99 copies
Fax Transmission Speed	33.6 kbps
Standard Paper Capacity	250 sheets
Connectivity	USB 2.0
Memory	32 MB
Operating System Compatibility	Windows, Mac OS
Duplex Printing	Manual
Scan Type	Flatbed
Media Sizes Supported	Letter, Legal, Executive, A4, A5
Media Weight	60 to 163 g/m²
Monthly Duty Cycle	10, 000 pages
Toner Yield	Up to 3, 000 pages
