Xerox Phaser 3200MFP Service Manual

Spare Parts List
Phaser 3200MFP / Workcentre PE220 04/07 5-23
PL 6.1 Paper Path Assembly (Phaser 3200)
Item Part Number Description Qt’y Remark
0 PAPER-PATH ASSEMBLY 1
1 038N00463 GUIDE-M-PAPER PATH 1
2 130N01497 FEED SENSOR ACTUATOR 1
3 009N01519 SPRING ETC-LEVER SENSOR 1
4 015N00558 IPR-PLATE SAW 1
5 CBF HARNESS-MICRO SWITCH
6 GROUND-P-SAW 1
7 GROUND-P-THV 1
8 GROUND-P-VARISTOR 1
9 019N00940 MEA UNIT-HOLDER_PAD 1
9-1 019N00837 HOLDER-M-PAD 1
9-2 019N00836 PAD-FRICTION 1
9-3 019N00837 HOLDER-M-PAD 1
9-4 009N01520 SPRING ETC-EXIT ROLL FD 1
10 007N01586 GEAR-FEED 1
11 007N01585 MEA UNIT-PICK UP GEAR 1
11-1 GEAR-PICK_UP A 1
11-2 GEAR-PICK_UP B 1
11-3 SPRING-CS 1
12 121N01078 SOLENOID 1
13 PMO-BUSHING FEED
14 ROLLER FEED
15 016N00281 PMO-BUSHING_TR(L)
16 009N01521 SPRING ETC-TR(12)
17 PICK UP UNIT (REFER TO PL 6.2
)
18 SHAFT FEED
19 IPR-P-EARTH TRANSFER
20 PLATE-P_IDLE HOLDER
21 ROLLER HOLDER ASSEMBLY
21-1 HOLDER-IDLE ROLLER
21-2 ROLLER-M-IDLE FEED
21-3 SPRING-ES

Xerox Phaser 3200MFP Specifications

General

Print Technology	Laser
Functions	Print, Copy, Scan, Fax
Print Resolution	Up to 600 x 600 dpi
First Page Out Time	Less than 10 seconds
Copy Resolution	Up to 600 x 600 dpi
Maximum Copy Count	99 copies
Fax Transmission Speed	33.6 kbps
Standard Paper Capacity	250 sheets
Connectivity	USB 2.0
Memory	32 MB
Operating System Compatibility	Windows, Mac OS
Duplex Printing	Manual
Scan Type	Flatbed
Media Sizes Supported	Letter, Legal, Executive, A4, A5
Media Weight	60 to 163 g/m²
Monthly Duty Cycle	10, 000 pages
Toner Yield	Up to 3, 000 pages
