Spare Parts List
Phaser 3200MFP / Workcentre PE220 04/07 5-25
PL 6.2 Pick Up Unit (Phaser 3200)
Item Part Number Description Qt’y Remark
0 022N02191 PICK UP UNIT 1
1 SHAFT-P-PICK UP 1
2 BRACKET-P-BAR PICK UP 1
3 PICK UP HOUSING B 1
4 PICK UP HOUSING A 1
5 PICK UP RUBBER 1
6 IDLE ROLLER PICK UP 2
7 PICK UP STOPPER RIGHT 1
8 PICK UP STOPPER LEFT 1
9 008N01762 PICK UP CAM 2
To Next Page
