Xerox Phaser 3200MFP Service Manual

Spare Parts List
Phaser 3200MFP / Workcentre PE220 04/07 5-27
PL 7.0 Fuser Unit (Workcentre PE220)
Item Part Number Description Qt’y Remark
0 101N01381 FUSER_220V 1
0 101N01380 FUSER_110V 1
1 FRAME-P-FUSER 1
2 COVER-M_FUSER 1
3 019N00839 HOLDER-M-EXIT R 2
4 007N01377 GEAR-EXIT_DRV17 1
5 HOLDER-M-EXIT F/DOWN 3
6 SPRING-CS 2
7 013N13843 BEARING-PRESSURE/R 2
8 GUIDE-M-INPUT 1
9 022N01611 ROLLER-PRESSURE 1
10 022N01610 ROLLER-HEAT 1
11 007N01205 GEAR-FUSER, Z37 1
12 016N00282 BUSH-M-HR L 1
13 016N00262 BUSH-M-HR R 1
14 122N00245 LAMP-HALOGEN_220V 1
14 122N00246 LAMP-HALOGEN_110V 1
15 ROLLER-M-EXIT MAIN 3
16 ROLLER-M_EXIT FR 3
18 009N01522 SPRING-CS 3
19 130N01417 THERMISTOR-NTC 1
20 130N01411 THERMOSTAT-150 1
21 152N11628 CBF HARNESS-FUSER JOINT 1
22 152N11626 CBF HARNESS-FUSER (220V) 1
22 152N11631 CBF HARNESS-FUSER (110V) 1
23 PADDLE 2
24 GEAR EXIT-DR38/25 1
25 WASHER-PLAIN 1
26 E-CLIP 1
27 STRIPPER FINGER 4
27-1 009N01523 SPRING ETC-STRIPPER FINGER 4
27-2 019N00840 HOLDER_M_PLATE STRIPPER FINGER 4
27-3 PLATE-P-STRIPPER FINGER 4
28 COVER-M-GUIDE EXIT 1
29 COVER-M-SAFETY FUSER 1
30 LEVER-M_ACT EXIT 1
31 SPRING ETC-TR(KOR) 1
32 HOLDER-M_ACTUATOR 1
33 NOT USED 1
34 LEVER-M-ACTUATOR JAM 1
35 PMO-BUSHING TX(B4) 1
36 SPRING ETC-TORSION DOC (CC2-F) 1

Xerox Phaser 3200MFP Specifications

General

Print Technology	Laser
Functions	Print, Copy, Scan, Fax
Print Resolution	Up to 600 x 600 dpi
First Page Out Time	Less than 10 seconds
Copy Resolution	Up to 600 x 600 dpi
Maximum Copy Count	99 copies
Fax Transmission Speed	33.6 kbps
Standard Paper Capacity	250 sheets
Connectivity	USB 2.0
Memory	32 MB
Operating System Compatibility	Windows, Mac OS
Duplex Printing	Manual
Scan Type	Flatbed
Media Sizes Supported	Letter, Legal, Executive, A4, A5
Media Weight	60 to 163 g/m²
Monthly Duty Cycle	10, 000 pages
Toner Yield	Up to 3, 000 pages
