Xerox Phaser 3200MFP Service Manual

Spare Parts List
Phaser 3200MFP / Workcentre PE220 04/07 5-29
PL 7.1 Fuser Unit (Phaser 3200)
Item Part Number Description Qt’y Remark
0 126N00275 FUSER_220V 1
0 126N00274 FUSER_110V 1
1 FUSER COVER 1
2 130N01498 THERMOSTAT 1
3 CBF HARNESS-FUSER 220V 1
3 CBF HARNESS-FUSER 110V 1
4 CBF HARNESS-FUSER JOINT 1
5 130N01499 THERMISTOR NTC ASSY 1
6 CAP-M-THERMO 1
7 HOLDER SPRING 3
8 SPRING CS 3
9 HOLDER-M-EXIT F/DOWN 3
10 ROLLER-M_EXIT_MAIN 3
11 ROLLER-M_EXIT FR 3
12 SPRING ES 4
13 002N00941 STRIPPER FINGER 4
14 IPR-PIN ROLLER EXIT 3
15 PEX-ROLLER F/UP(2) 3
16 EXIT GEAR_DR38/25 1
17 WASHER 1
18 CS-RING 1
19 122N00270 HALOGEN LAMP 220V 1
19 122N00269 HALOGEN LAMP 110V 1
20 022N02310 HEAT ROLLER 1
21 RIGHT BUSH 1
22 LEFT BUSH 1
23 FUSER GEAR 1
24 022N01611 PRESSURE ROLLER 1
25 PRESSURE ROLLER BUSH 2
26 ETC SPRING-PR 2
27 FUSER FRAME 1
28 GUIDE-M-INPUT 1
29 COVER LAMP RIGHT 1
30 COVER LAMP LEFT 1
31 FUSER SHEET 1
32 ROLLER-EXIT F/DOWN 1
33 HOLDER-EXIT RIGHT 2
34 EXIT_DRV17 1
35 FRONT FUSER COVER 1
36 PMO-SUB STACKER 2
37 FUSER SAFETY COVER 1
38 JAM SENSOR ACTUATOR 1
39 SPRING ETC-TR 1

Xerox Phaser 3200MFP Specifications

General

Print Technology	Laser
Functions	Print, Copy, Scan, Fax
Print Resolution	Up to 600 x 600 dpi
First Page Out Time	Less than 10 seconds
Copy Resolution	Up to 600 x 600 dpi
Maximum Copy Count	99 copies
Fax Transmission Speed	33.6 kbps
Standard Paper Capacity	250 sheets
Connectivity	USB 2.0
Memory	32 MB
Operating System Compatibility	Windows, Mac OS
Duplex Printing	Manual
Scan Type	Flatbed
Media Sizes Supported	Letter, Legal, Executive, A4, A5
Media Weight	60 to 163 g/m²
Monthly Duty Cycle	10, 000 pages
Toner Yield	Up to 3, 000 pages
