General Procedures and Information
Phaser 3200MFP / Workcentre PE220 04/07 6-21
Developer Process
- Developing Method: Non magnetic 1 element contacting method
- Toner: Non magnetic 1 element shatter type toner
- Toner Qty:35gf /60gf (1k/3k)
- The life span of toner 3k sheets (ISO 5% Coverage)
- Toner Residual Sensor: None
- OPC Cleaning: Use the conventional cleaning blade
- OPC Drum Protecting Shutter: None
- Classifying device for print cartridge: ID is classified by interruption of the frame channel.
- Development Roller type: conductive elastic roller
- Doctor BLADE Type: Regulating toner layer by pressure
- Charge Roller Type: Conductive Roller Contact-Charge
Fuser Specification
1) Heat Lamp
- Heat Lamp Terminal Shape: Terminal Single Type
- Voltage 120 V: 115 ± 5 %, 220 V: 230 ± 5 %
- Capacity: 600 Watt ± 30 W
- Light Qty Distribution: 140%
- Life: 3000 Hr
2) Thermostat
- Thermostat Type: Non-Contact type THERMOSTAT
- Control Temperature: 150°C + 5°C
3) Thermistor
- Thermistor Type: HF-R0060 (SEMITEC 364FL Type)
- Temperature Resistance: 7 k Ω(180 °C)
- SYSTEM Temperature SETTING
• Stand by: 165 ± 5°C
• Printing: 175 ± 5°C(5 minutes before)
170°C ± 5°C(5 minutes before)
• Overshoot: 200°C or less
• Overheat:210°C or less
4) Safety Relevant Facts
- Protection device when overheating
• 1st protection device: H/W cuts off when detecting an overheating
• 2nd protection device: S/W cuts off when detecting overheating
• 3rd protection device: Thermostat cuts off the power
- Safety device
• The power of Fuser is cut-off after front cover is open.
• The overheating safety device for customer
• The surface temperature of the Fuser Cover is under 80°C
