Xerox WorkCentre 5024 User Manual

Problem Solving
Xerox
®
WorkCentre
®
5022/5024 Multifunction Printer
User Guide
13-41
072-105 A paper jam occurred in the one tray module
cover B.
Remove the jammed paper.
Refer to Paper Jams on page 13-46.
072-210
072-212
072-215
An error occurred in Tray 2 (One Tray Module). Switch off the machine power, make sure
that the display is blank, and then switch on
the machine power. If the same message is
displayed again, contact our Customer
Support Center.
073-102 A paper jam occurred in the two tray module
cover C or Tray 3.
Remove the jammed paper.
Refer to Paper Jams on page 13-46.
073-104 A paper jam occurred in the one tray module
cover B or the two tray module cover C.
Remove the jammed paper.
Refer to Paper Jams on page 13-46.
073-105 A paper jam occurred in the one tray module
cover B.
Remove the jammed paper.
Refer to Paper Jams on page 13-46.
073-210 An error occurred in Tray 3 (Two Tray Module). Switch off the machine power, make sure
that the display is blank, and then switch on
the machine power. If the same message is
displayed again, contact our Customer
Support Center.
074-101
074-102
A paper jam occurred in the two tray module
cover C or Tray 4.
Remove the jammed paper.
Refer to Paper Jams on page 13-46.
074-104 A paper jam occurred in the one tray module
cover B or the two tray module cover C.
Remove the jammed paper.
Refer to Paper Jams on page 13-46.
074-105 A paper jam occurred in the one tray module
cover B.
Remove the jammed paper.
Refer to Paper Jams on page 13-46.
074-210 An error occurred in Tray 4 (Two Tray Module). Switch off the machine power, make sure
that the display is blank, and then switch on
the machine power. If the same message is
displayed again, contact our Customer
Support Center.
075-135
077-101
077-103
077-104
077-106
A paper jam occurred in the left cover A. Remove the jammed paper.
Refer to Paper Jams on page 13-46.
077-129 A paper jam occurred in the left cover A. Remove the jammed paper.
Refer to Paper Jams on page 13-46.
077-211 An error occurred in the Two Tray Module. Switch off the machine power, make sure
that the display is blank, and then switch on
the machine power. If the same message is
displayed again, contact our Customer
Support Center.
Error Code Cause Remedy

Xerox WorkCentre 5024 Specifications

General

Duplex printing	Yes
Print technology	Laser
Maximum resolution	600 x 600 DPI
Time to first page (black, normal)	14 s
Print speed (black, normal quality, A3)	12 ppm
Print speed (black, normal quality, A4/US Letter)	24 ppm
Duplex print speed (black, normal quality, A4/US Letter)	17 ppm
Copy speed (black, normal quality, A3)	12 cpm
Copy speed (black, normal quality, A4)	24 cpm
Scan to	E-mail, PC
Scan drivers	TWAIN
Scanner type	ADF scanner
Scan speed (black)	22 ppm
Scan speed (color)	13 ppm
Faxing	-
Modem speed	33.6 Kbit/s
Printing colors	Black
Maximum duty cycle	25000 pages per month
Recommended duty cycle	0 - 25000 pages per month
Number of print cartridges	2
Wi-Fi	No
Email protocols	SMTP
Cabling technology	10/100Base-T(X)
Ethernet LAN data rates	10, 100 Mbit/s
Internal memory	256 MB
Standard interfaces	USB 2.0
Display	LCD
Product color	Gray
Market positioning	Business
Windows operating systems supported	Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64, Windows 8.1, Windows 8.1 Enterprise, Windows 8.1 Enterprise x64, Windows 8.1 Pro, Windows 8.1 Pro x64, Windows 8.1 x64, Windows Vista Business, Windows Vista Business x64, Windows Vista Enterprise, Windows Vista Enterprise x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64
Paper input type	Paper tray
Total input capacity	350 sheets
Total output capacity	- sheets
Maximum input capacity	1850 sheets
Total number of input trays	5
Paper tray media types	Labels, Plain paper, Recycled paper
Paper tray media weight	60 - 90 g/m²
ISO A-series sizes (A0...A9)	A3, A4
ISO B-series sizes (B0...B9)	B4, B5
Maximum ISO A-series paper size	A3
Power consumption (average operating)	- W
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Depth	574 mm
Width	594.3 mm
Height	581.6 mm
